LTE AG35 series AG35EUTDA-512-UGASG automotive-grade LTE Cat 4 module

Automotive-grade LTE Cat 4 module LGA package Supports up to 150 Mbps downlink rate and 50 Mbps uplink rate under LTE network Ultra-wide temperature range (-40 °C ~ +85 °C)

RÉS8 -- RÉS8 six-group conversion sealed DC electromagnetic relay

Contact load capacity: 2A 6 sets of switching contacts Temperature range (°C): -55~85 Sinusoidal vibration: 10~500Hz 58.8m/s² Shock (m/s²): 117.6 Contact form: 6Z Contact load and life: Resistive: 2A, 27Vd.c., 1x10⁵ cycles Dimensions (mm): Φ29.5x33 Weight (g): ≤75

Monocular night vision device

Monocular night vision goggles are used for night-time operations, reading, maintenance, observing the surrounding environment, etc. 1. Can be used handheld, directly worn, or connected to a helmet; 2. Has auxiliary lighting function; 3. Allows for left and right eye interchangeable observation; 4. Has undervoltage indication and reverse battery protection function.

Handheld night vision device

Handheld night vision devices are used for nighttime operations, reading, maintenance, and observing the surrounding environment. 1. Under clear, moonless, starry sky conditions, the human recognition distance is greater than 60 meters; 2. Field of view: 27°×20°; 3. Main unit weight: 220g; 4. Magnification: 1×; 5. Operating temperature: -20℃～+40℃; 6. Protection level: IP67.

JCGTT155 Three-axis, three-light stabilized positioning and guidance pod

The JCGTT155 is a miniature three-axis, three-light inertial stabilized positioning pod that integrates a long-wave uncooled infrared camera, a high-definition visible light camera, a laser rangefinder, and a gyro-stabilized platform.

JQ-7717F DC Contactor -- PHE22-24B -27B

1. This product has two sets of make contacts and two sets of break contacts, and can also be easily reconnected as two sets of changeover contacts. It is mainly used for switching circuits in the fields of weaponry and ships. Product Parameters Temperature Range: -55～85℃ Sinusoidal Vibration: 10～500Hz 98m/s² Contact Form: 2H2D Contact Load and Life: 50A, 28Vd.c.(resistive), 5×10⁴ times Size: 70×30×51mm Weight: ≤250g

JQX-7817 -- EDT2 balanced force electromagnetic relay, rail relay

1 cubic inch balanced armature electromagnetic relay, with one control winding, two sets of normally open contacts, two sets of normally closed contacts, can switch 1A, 110Vd.c.; 3A, 72Vd.c. resistive load, used in the rail transit field switching circuit.

JQX-7303M -- ETP4 balanced force electromagnetic relay, rail relay

1 cubic inch balanced armature electromagnetic relay, with one control winding, four sets of changeover contacts, can switch 0.5A, 110V d.c. resistive loads, and can be used in fields such as railway locomotives to switch circuits.

JQX-7811M type -- ETP6 1H1E balanced force electromagnetic relay rail relay

1.5 cubic inch balanced armature electromagnetic relay, with one control winding, six sets of changeover contacts, capable of switching 0.5A, 110V d.c. resistive loads, used in fields such as railway locomotives for circuit switching.

RES47 0203 -- RES47 0102 miniature hermetically sealed DC electromagnetic relays with reliability indicators

2A Contact Load Capacity Two sets of switching contacts Temperature range: -65~125℃ Sine vibration: 10~3000Hz 249m/s² Size: 20.5*10.5*10.5mm Weight: ≤11g

JQ-7686F type three-phase contactor -- TKS203DOD

200A Contact Load Capacity Three-phase AC contactor, strong overload capacity, high reliability. Mainly used in the fields of weapons, ships, military electronics, etc., for switching circuits. Temperature range: -55 to 85℃ Sine vibration: 5 to 200Hz, 49m/s² Contact form: 3H Contact load and lifespan: 200A, 115/200Va.c., 400Hz (resistive), 2×10⁴ times Size: 144×92×118mm Weight: ≤2000g

JQ-7040F type DC contactor -- KM-200DV

200A Contact Load Capacity A set of moving contact overload capacity is strong and environmental adaptability is strong. Mainly used for switching circuits in vehicles, ships, or ground equipment. Temperature range: -55 to 85℃ Sine vibration: 10 to 2000Hz, 34.3m/s² Contact form: 1H Contact load and lifespan: 200A, 27Vd.c. (resistive), 2×10⁴ times Size: 85.5×56×84.5mm Weight: ≤480g
